Chromium Etchant, Cerium content - 2.50 - 5.10 %

Others


Linear Formula:  NA
Molecular Weight:  NA
CAS Number: NA

Properties

Water Solubility at 20 °C soluble
B pt. 100 °C/1 atm
Density 1.16 g/mL at 25 °C
Form Liquid

Safety Information

Hazard Statement(s) H272,H290,H314,H317,H411
Precautionary Statement  P210 - P220 - P273 - P280 - P303 + P361 + P353 - P305 + P351 + P338
GHS Pictogram
Signal word Danger
Storage Temp. Room Temperature
Storage Class 5.1B - Oxidizing hazardous materials
UN Number 3093

Description

Application
Chromium etchant containing cerium is used to remove thin layers of chromium from glass silicon wafers and metal surfaces during manufacturing and microfabrication processes.

Purpose
The purpose of chromium etchant with cerium is to selectively dissolve chromium without significantly damaging the underlying material allowing precise patterning and surface preparation.

General Description
Chromium etchant with cerium is a chemical solution that typically contains ceric ammonium nitrate along with acids such as nitric or acetic acid to efficiently oxidize and dissolve chromium coatings. It is commonly used in electronics semiconductor fabrication and photolithography.
